- Material: Available in 18,16 or 14-gauge front cover
- Heights:9-7/8″ (one tier) 14″ (one tier) 21″ (one or two tier) 28″ (up to three tier)
- Lengths: 2' to 8'
- Depth: 5-1/4″
J Series fin tube enclosures are functional and durable units. J Series is popular for deluxe commercial installations, schools, offices, hospitals, churches and office buildings. The sloping louvered top is attractive and prevents use of the enclosure as a shelf or seat.
Related products
-
The Kicker
- Application: Hot water
- Voltage: 120 VAC, 60 Hz.
- Output: 5075 – 7227 (180 Deg. 1 GPM)
- Range: 140 - 220 Btuh ˚F
- High performance manifold-type heat exchanger
- Two built-in air vent tappings. Coin or screwdriver access.
- Brazed tube joints resist rigors of installation and years of operation
- 1/2" hot water supply and return fittings
- Aluminum turbo fin heat exchanger maximizes heat transfer
- Expanded copper tube bonds fin to copper for high heat transfer
- Heavy duty 2-speed blower motor for extended life. Internally cooled. Permanently lubricated.
- Aluminum squirrel cage blower
- Aquastat permits blower operation only when the water temperature is above 130°F
- Three-position blower switch is easily accessible
- Hot dipped galvanized chassis resists rust and corrosion
- Rubber grommets cushion chassis for quiet operation
- 22" matte black grille
-
HD Series
- Material: 16-ga. steel front cover, 20-ga. back panel
- Heights: 8-1/2" (one tier) & 14" (two tier)
- Depth: 3-1/2"
- Lengths: 2' - 8'
- Heavy gauge enclosure and support brackets
- Cover secures together with screws at each bracket location
- 3/4", 1" and 1-1/4" copper/aluminum elements permit higher flow rates, longer series-loop runs and lower pump loads where required
- 1-1/4" all-steel element, for use in one or two pipe steam systems
- Factory pre-assembled in individual cartons for rapid installations
- Finish: Galvanized is standard. Available in baked enamel
- Custom color available on special order
- Telescopic cover accessories
- Accessories have a screw hole to secure accessories to front cover
- Pan head screws supplied by others
- The picture on the right is an HD-850 installation in the Milwaukee Airport baggage claim area. This installation was done years ago. It is installed right by the cart area and receives a lot of abuse. Please note other than some paint damage it is in great shape. Seeing is believing, This is indeed “Tough Stuff” and it would be tough finding a higher abuse area to install it in.
-
FS Series
- Material: FS-7: 18/16/14 ga.,
FS-14 & FS-21: 16/14 ga. - Heights: 11" (one tier), 18" (two tier) 25" (three tier)
- Depth: 5-1/2"
- Lengths: 2' to 8'
- Rugged floor mounted top outlet cover
- Up to 3 Tiers for higher output
- Aluminum Grill Option
- Decorator Colors Available Upon Request
- Ideal for use with High Efficiency Boilers
- Choice of 5 commercial copper or steel elements
- Material: FS-7: 18/16/14 ga.,
-
RAG Series
- Material: 18, 16 & 14 ga.
- Heights: 9-7/8" (one tier), 14" (one tier), 21" (two tier) & 28" (three tier)
- Lengths: 2' to 8'
- Depth: 5-1/4"
- High Output Rugged Flat Top Cover
- Up to 3 tiers for higher output
- Standard with Top Outlet; Front and Top/Front Outlet options
- Aluminum Grill Standard
- Decorator Colors Available Upon Request
- Ideal for use with High Efficiency Boilers
- Choice of 6 commercial copper or steel elements
- Material: 18, 16 or 14 gauge
- Heights: 9-7/8" (one tier), 14" (one tier), 21" (two tier), & 28" (three tier)
- Lengths: 2' to 8'
- Depth: 5-1/4"
- Single-piece cover mounts on wall brackets
- Optional Damper
- Galvanized finish is standard. Baked enamel available.
- Copper with aluminum fins: C-340, C-440, C-540
- Steel with electro-galvanized steel fins: S-532, S-540, S-832
- Connectors align cover sections which butt to one another, providing a near seamless joint
- Uses internal or external splice plate.
- Telescopic accessories
Slant/Fin baseboard provides gentle full room convection heating that blocks chilling drafts at the outside walls. Slant/Fin hot water baseboard heating surrounds your customers with heating comfort. Natural convection perimeter heating blocks chilling drafts at the outside walls where they originate. No annoying on-and-off blowing ducts. No dirt and germs blown through forced air system. Easy to zone for room by room comfort control.
